Description
Jabsco 24V Macerator Pump | Boat Supply Store
Efficiently evacuate waste and debris from onboard systems with the Jabsco 24V Self-Priming Sealed Macerator Pump. Engineered with a high-performance four-bladed chopper, this unit minimizes clogs for reliable discharge. Its automatic run-dry protection with a shut-off sensor prevents motor damage, and the 4ft self-priming capability ensures consistent operation. Boaters on the Texas coast dealing with holding tanks or clearing fish boxes will find its 12 GPM flow rate and 15-minute continuous duty cycle indispensable.
Key Features
- Run-Dry Protection with automatic shut-off sensor prevents catastrophic motor failure.
- Triple Sealed Motor construction ensures superior corrosion resistance in harsh marine environments.
- Clog Reduction via a new four-bladed chopper design for smoother waste processing.
- Self-Priming Capability up to 4ft vertical lift for flexible installation and reliable operation.
- High Flow Rate of 12 GPM for rapid evacuation of waste and debris.
- Versatile Application suitable for holding tanks, fish boxes, and livewell discharge.
- Sustained Performance with a 15-minute continuous duty cycle.
- Robust Inlet Options including 1-1/2" NPT and 1-1/2" hose barb for diverse plumbing configurations.
Specifications
| Product Specifications | |
|---|---|
| Voltage | 24V DC |
| Flow Rate | 12 GPM |
| Self-Priming Lift | 4ft |
| Duty Cycle | 15-minute |
| Inlet | 1-1/2" NPT/Hose Barb |
| Outlet | 1" Hose Barb |
| Motor Construction | Triple-sealed |
| Chopper Type | Four-bladed |
| Run-Dry Protection | Automatic shut-off sensor |
Who This Is For
Boaters with holding tanks, fish boxes, or livewells requiring efficient and reliable waste or debris evacuation. Ideal for those needing self-priming capabilities or protection against running dry during operation.
How It Compares
| Feature | Jabsco 24V Macerator Pump | Seaflo 3 |
|---|---|---|
| Voltage | 24V | 24V |
| Flow Rate | 12 GPM | up to 12 GPM |
| Self-Priming | Yes, to 4ft | Yes |
| Macerator/Chopper | Yes, 4-bladed | No |
| Run-Dry Protection | Yes, automatic shut-off | No |
| Duty Cycle | 15 minutes continuous | Intermittent |
| Inlet Port | 1-1/2" Hose Barb plus 1-1/2 NPT | Varies by model, typically 1-1/8" or 1-1/2" hose barb |
| Discharge Port | 1" Hose Barb | Varies by model, typically 1-1/8" or 1-1/2" hose barb |
Common Concerns Answered
Will this pump clog easily?
The Jabsco 18590-2094 features a new four-bladed chopper designed specifically to minimize clogging, however, proper maintenance and avoidance of overly large solids are recommended for optimal performance.
Is this pump expensive?
While the initial cost is higher than basic bilge pumps, the Jabsco 18590-2094 offers advanced features like run-dry protection and a powerful macerator, providing long-term value and reliability for critical sanitation tasks.
What happens if the run-dry sensor fails?
Occasional reports of run-dry sensor issues exist, potentially requiring a reset. The robust triple-sealed motor construction provides some inherent protection against dry running, but it is always best practice to ensure adequate fluid levels.
Frequently Asked Questions
What is the flow rate of the Jabsco 18590-2094 macerator pump?
The Jabsco 18590-2094 macerator pump has a flow rate of 12 GPM (gallons per minute).
Can this Jabsco macerator pump run dry without damage?
Yes, the Jabsco 18590-2094 is equipped with run-dry protection featuring an automatic shut-off sensor to prevent damage if it runs dry.
What is the maximum lift or priming height for this pump?
This Jabsco macerator pump can self-prime up to a vertical lift of 4 feet.
What size hose barb fittings does this pump have?
The inlet port accommodates 1-1/2" hose barb or 1-1/2" NPT fittings, and the discharge port utilizes a 1" hose barb fitting.
How long can the Jabsco 18590-2094 pump run continuously?
The Jabsco 18590-2094 pump is rated for a 15-minute continuous duty cycle.
