Shurflo Macerator Pump 24V 13GPM | Boat Supply Store
This self-priming macerator pump is engineered for demanding marine sanitation applications, efficiently evacuating waste and clearing fish boxes. It boasts a robust dual-blade design capable of processing solids and operates effectively on 24 VDC systems with a substantial 13 GPM flow rate. Its run-dry capability and ignition-protected construction ensure reliability and safety in harsh offshore environments.
Key Features
- Self-Priming for effortless operation without manual priming.
- Dual Blade efficiently grinds waste for unobstructed flow.
- Run-Dry Capability protects the pump from damage if water supply is interrupted.
- Sealed Motor with o-ring sealed end bells prevents moisture ingress.
- Thermally Protected motor to prevent overheating and ensure longevity.
- Ignition Protected for safe installation in gasoline-powered engine compartments.
- Seamless Shell Motor enhances durability in corrosive marine atmospheres.
- Sealed Manual Turn Key for emergency manual operation.
Specifications
| Product Specifications | |
|---|---|
| Voltage | 24 VDC |
| Flow Rate | 13 GPM (49 LPM) |
| Amperage | 9 Amps (Max.) |
| Inlet Barb Size | 1-1/2" [38.1mm] |
| Outlet Port Size (NPT) | 1-1/2" [38.1mm] |
| Outlet Barb Size | 1" [25.4mm] |
| Dimensions | 10.6" [269mm] x 4.9" [125mm] x 3.8" [97mm] |
Who This Is For
Boat owners and marine maintenance professionals requiring a dependable and heavy-duty solution for sewage evacuation and fish box discharge in 24VDC electrical systems. This pump is ideal for vessels needing reliable waste management in challenging saltwater conditions.
How It Compares
| Feature | Shurflo Macerator Pump 24V 13GPM | Diaphragm Pump |
|---|---|---|
| Voltage | 24 VDC | 12 VDC, 24 VDC |
| Flow Rate | 13 GPM | 12 GPM, 12 GPM |
| Maceration Blades | Dual Blade | Single Blade (typical), N/A |
| Run-Dry Capability | Yes | Yes (typical for Jabsco macerators), Yes |
| Ignition Protected | Yes | Yes (typical for marine macerators), Yes |
Common Concerns Answered
What is the return policy if I have an issue with the pump?
In the event of product issues, direct manufacturer contact with Pentair is required, as returns to the original point of purchase are not permitted.
How durable is the impeller system?
While generally robust, occasional reports indicate impeller wear may occur with prolonged, heavy operational use.
Why is the return policy manufacturer-direct?
This policy ensures specialized support for technical marine equipment, allowing Pentair to directly address any performance or warranty claims efficiently.
Frequently Asked Questions
What is the maximum flow rate of the Shurflo by Pentair 3200-011 Macerator Pump?
The Shurflo by Pentair 3200-011 Macerator Pump offers a maximum flow rate of 13 Gallons Per Minute (GPM), equivalent to 49 Liters Per Minute (LPM).
What voltage system is this macerator pump designed for?
This macerator pump is designed to operate on a 24 VDC (Volts Direct Current) electrical system.
What are the specified inlet and outlet port dimensions for the Shurflo 3200-011 pump?
The pump features a 1-1/2" [38.1mm] inlet barb and both a 1-1/2" [38.1mm] NPT outlet port and a 1" [25.4mm] barb outlet.
Can the Shurflo by Pentair 3200-011 pump operate without water for short periods?
Yes, this macerator pump is built with run-dry capability, meaning it can operate without water for a limited duration without sustaining damage.
Is the Shurflo 3200-011 pump safe to use in potentially explosive marine atmospheres?
Yes, the pump is ignition protected, making it safe for installation in compartments containing gasoline engines or other potentially flammable vapors.
