Uflex Boss Fitting for Outboard Steering | Boat Supply Store
Maintain optimal performance and system integrity of your Uflex outboard steering with this complete boss fitting, specifically engineered for bleed operations. This component utilizes precise ORB (O-Ring Boss) connections, featuring a 9/16 - 18 UNF 2A thread on the cylinder side and a 9/16 - 24 UNEF 2A thread on the hose side for secure attachment. It is essential for effectively purging air from hydraulic steering cylinders, ensuring responsive control for any vessel navigating coastal waters or inland lakes.
Key Features
- Complete Boss Fitting for seamless integration.
- Essential Bleed fitting for all outboard steering cylinders.
- Secure ORB fitting ensures leak-free hydraulic connections.
- Precise Size #6 to 3/8 COMP FITTING for Uflex systems.
- Accurate Cylinder Side Thread: 9/16 - 18 UNF 2A.
- Reliable Hose Side Thread: 9/16 - 24 UNEF 2A.
- Durable construction for marine environments.
- Guaranteed system integrity and proper bleeding.
Specifications
| Product Specifications | |
|---|---|
| MPN | BOSS FITTING |
| Application | Bleed fitting for all outboard cylinders |
| Cylinder Side thread | 9/16 - 18 UNF 2A |
| Hose Side thread | 9/16 - 24 UNEF 2A |
| ORB connection | Yes |
| Size | #6 to 3/8 COMP FITTING |
Who This Is For
This fitting is designed for boat owners and marine mechanics performing maintenance or upgrades on Uflex outboard steering systems. It is ideal for those requiring a precise bleed fitting with ORB connections for enhanced system performance and reliability.
How It Compares
| Feature | Uflex Boss Fitting for Outboard Steering | Standard Threads |
|---|---|---|
| Type | Complete Boss Fitting (Bleed Fitting) | Bleeder Fitting Kit |
| Cylinder Side Thread | 9/16 - 18 UNF 2A | 9/16-18 UNF |
| Hose Side Thread | 9/16 - 24 UNEF 2A | 9/16-20 UNF |
| ORB Connection | Yes (#6 to 3/8 COMP FITTING) | No |
Common Concerns Answered
How do I ensure compatibility with my existing steering system?
Verify that your current steering system utilizes ORB fittings and confirm the thread specifications match the 9/16 - 18 UNF 2A (cylinder side) and 9/16 - 24 UNEF 2A (hose side) of this Uflex Complete Boss Fitting. Consulting your system's manual or a marine technician is recommended.
What is the difference between ORB sizes and standard threads?
ORB (O-Ring Boss) fittings create a seal via an O-ring compressed into a groove, providing superior leak resistance compared to standard threads which rely on the tapered pipe threads for sealing. This Uflex fitting exclusively uses ORB connections for optimal hydraulic performance.
Will this fitting work if I don't have a Uflex steering system?
While this fitting is specifically designed for Uflex outboard steering systems, its precise ORB connections and thread specifications may offer compatibility with other systems that utilize the same thread types and are designed for bleed fittings. Always confirm compatibility before purchase.
Frequently Asked Questions
What is the Uflex Complete Boss Fitting used for?
The Uflex Complete Boss Fitting is used as a bleed fitting for Uflex outboard steering cylinders to effectively remove air from the hydraulic system, ensuring smooth and responsive steering.
What are the thread sizes for the Uflex Complete Boss Fitting?
The cylinder side thread is 9/16 - 18 UNF 2A, and the hose side thread is 9/16 - 24 UNEF 2A. Both are precision-machined for secure ORB connections.
Is this fitting compatible with all outboard steering cylinders?
This fitting is specifically designed for Uflex outboard steering cylinders. While it features standard ORB thread dimensions, compatibility with non-Uflex systems should be verified based on the cylinder's thread type and size.
What type of fitting is the Uflex Complete Boss Fitting?
It is a complete boss fitting that incorporates an ORB (O-Ring Boss) connection, functioning as a bleed fitting for hydraulic steering systems.
What is the size #6 to 3/8 COMP FITTING referring to?
The '#6 to 3/8 COMP FITTING' notation indicates the size of the O-ring boss and the compatible compression fitting size, ensuring proper seal and connection for the #6 ORB port to a 3/8" component.
