Veratron LinkUp Analog to NMEA 2000 Gateway | Boat Supply Store
Seamlessly integrate legacy analog marine sensors into a modern NMEA 2000 network with the Veratron LinkUp Gateway. This device effectively converts resistive analog signals from sensors such as fuel level, pressure, temperature, trim tabs, and rudder angle into standardized NMEA 2000 PGNs, simplifying data aggregation on vessels equipped with older instrumentation. Operating within a 6-16.5V range and boasting an IPX7 ingress protection rating, it ensures robust performance even in harsh marine environments, facilitating data recovery and programming via its bi-directional communication capabilities.
Key Features
- Converts resistive-type analog signals to NMEA 2000 for seamless integration.
- Simplifies installation by replacing original sensor wiring directly.
- Utilizes the NMEA 2000 backbone for its power source, eliminating extra wiring.
- Offers wireless configuration via a companion smartphone app for Android and iOS devices.
- Features NFC tap-to-download functionality for rapid parameter setup.
- Supports a diverse range of critical marine sensors, including fuel level, pressure, temperature, trim tabs, and rudder angle.
- Provides IPX7 water resistance for durability in wet marine conditions.
- Enables bi-directional communication for efficient programming and data recovery.
Specifications
| Product Specifications | |
|---|---|
| Analog Input Type | Resistive |
| NMEA 2000 Plug | M12 |
| Sensor Plug | Superseal Female 2 Pin |
| Operating Voltage | 6-16.5V |
| IP Rating | IPX7 |
| Sensor Cable Length | 25cm |
| NMEA 2000 Cable Length | 25cm |
| Configuration Method | Wireless (NFC Tap) via Smartphone App |
Who This Is For
This gateway is designed for boat owners and marine technicians seeking to upgrade existing analog sensor systems to a NMEA 2000 network without undertaking a complete hardware replacement. It provides a cost-effective solution for integrating essential sensor data into modern digital marine electronics.
How It Compares
| Feature | Veratron LinkUp Analog to NMEA 2000 Gateway | NGW-1 |
|---|---|---|
| Analog Input Type | Resistive | Resistive, Voltage, Frequency |
| Configuration Method | Wireless (NFC Tap) via Smartphone App | PC Software |
| Number of Analog Inputs per Unit | 1 | 8 |
| Power Source | NMEA 2000 Backbone | NMEA 2000 Backbone |
| IP Rating | IPX7 | IPX5 |
Common Concerns Answered
What if my boat has multiple analog sensors?
The Veratron LinkUp Gateway is designed to convert one analog sensor per unit. For boats with multiple analog sensors, you will need to install a separate LinkUp Gateway for each sensor to integrate them into the NMEA 2000 network.
What is the customer sentiment towards this product?
Customers express positive sentiment, particularly praising the ease of use and the advanced wireless configuration capabilities facilitated by the smartphone application.
Can the fixed sensor cable length be an issue?
The 25cm sensor cable length is fixed. For installations requiring longer cable runs between the sensor and the LinkUp Gateway, appropriate NMEA 2000 or equivalent sensor extension cables will be necessary.
Frequently Asked Questions
What is the Veratron LinkUp Analog to NMEA 2000 Gateway?
The Veratron LinkUp Gateway is a device that converts resistive analog sensor data into the NMEA 2000 digital communication standard, allowing older sensors to communicate with modern marine electronics.
How does the Veratron LinkUp Gateway convert analog signals to NMEA 2000?
It takes the analog signal from a connected resistive sensor, processes it, and translates it into a standardized NMEA 2000 message (PGN) that can be transmitted over the NMEA 2000 backbone.
What types of sensors can the Veratron LinkUp Gateway support?
It supports a wide array of resistive analog sensors, including fuel level senders, pressure transducers, temperature sensors, trim tab position sensors, and rudder angle sensors.
How is the Veratron LinkUp Gateway configured?
Configuration is performed wirelessly using a companion smartphone app (available for Android and iOS) via NFC tap functionality to download specific sensor parameters.
What is the IP rating of the Veratron LinkUp Gateway?
The Veratron LinkUp Gateway has an IPX7 rating, meaning it is protected against immersion in water up to 1 meter for 30 minutes, ensuring its durability in marine environments.
